Single Rotary High Speed Paper Sheeter 1100mm Paper Sheet Cutting Machine

Single Rotary High Speed Paper Sheeter 1100mm Paper Sheet Cutting Machine

Brand Name:	CHM Machinery
Model Number:	CHM-1100/1400/1700/1900
MOQ:	1 SHE
Price:	60000-120000 USD
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	200 SETS

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product:

Paper Roll To Sheet Cutting Machine

Voltage:

380V

Power:

22kw 27kw

Max Speed:

300 Cuts/min

Packaging Details:

Stretch Film, shipping mark, bubble wrap

Highlight:

Single Rotary High Speed Paper Sheeter

High Speed Paper Sheeter 1100mm

Single Rotary paper sheet cutting machine

Product Description

CHM Precision Single Rotary Sheeter Cutter Paper Machine

High Speed Single Rotary Paper Sheeting Machines

This machine excels in processing thin paper. The number of Unwind Stands can be increased to accommodate various paper types. For example, it can simultaneously sheet 4-6 rolls of 70-gram double-sided paper with ease.

Capable of cutting 95% of paper types in the market, this high-speed machine reaches up to 400 cuts per minute. It offers power efficiency, high precision, and can be operated by a single person. Ideal for paper mills, distributors, and printing operations.

Main Technical Parameters

Parameter	Specification
Model	CHM-1100
Type of Cutting	Top blade rotary, bottom blade fixed
Weight of Paper	60-500 GSM
Reel Diameter	Max 1500mm (59")
Finished Width	Max 1100mm (43")
Finished Sheet Length	Min. 450 - Max. 1300 mm
Number of Rolls Cutting	2 rolls
Cutting Accuracy	±0.5mm (L < 1000mm) ±0.1% (L ≥ 1000mm)
Max Speed of Cutting	300 cuts/min
Max Cutting Speed	300 m/min
Requirement of Air Pressure	0.8 MPa
Voltage	AC 380V/220V x 50Hz
Total Power	22 KW
Output	Dependent on material, paper weight, and operating process

Standard Configuration

Max Reel diameter: 1500mm (59")
Max Reel width: 1100mm (43")
Min Reel width: 350mm (14")
Core size: 3", 6", 12" (Cone chuck)
HYD. Driving: 3.75kw
Clip arm move forward or back driven by HYD
Clip arm up or down driven by HYD
Pneumatic brake system
Dancing roll with related bracket

Middle Slitting and Waste Edge Collecting System

Style

Adjustable slitting knife and exhaust tube for waste edge on both sides.

Top slitter

Adjustable up or down, slitting width can be adjusted manually.

Bottom slitter

Fixed slitters with manually adjustable slitting width.

Windmill

Driven by motor.

Type-Y collecting pipe

For waste edge collection.

High Precision Single Rotary Sheet Cutter Features

Top Tool Apron: Advanced cutting method reduces noise and load while extending knife life
Bottom Tool Apron: Cast and processed for maximum stability
Main driving roller: Grainy surface with air pressure control for optimal paper grip

As manufacturers specializing in paper sheeter machines and A4 production lines since 2004, CHM Machinery has grown into a professional manufacturer with three factories across Guangdong, Shandong, and Jiangsu, covering nearly 140,000 square meters. We are the world's second largest sheeting machine manufacturer with independent production capacity.

Our professional R&D and after-sales teams support our global customer base. Since introducing the single knife sheeter in 2006, we've sold over 200 units annually to more than 100 countries worldwide.

We can verify if your country already has our equipment installed. Please share your detailed requirements including paper type, gram weight, width, and capacity so we can recommend the most suitable model for your needs.

www.chmsheeter.com
Email: chm017@szchm.com
WhatsApp/WeChat: 86-13215242947 (Ms. Ada)
