| Brand Name: | CHM Machinery |
| Model Number: | CHM-SGT1400/1700H |
| MOQ: | 1 set |
| Price: | 160000-300000 |
| Payment Terms: | L/C,D/A,D/P,T/T |
| Supply Ability: | 200 sets |
High Precision Synchronize-fly Sheeter features fiber-less clean cuts with high dimensional precision. Ideal for board paper, art paper, kraft paper, packing paper, and various board materials.
High Precision Synchronize-fly Sheeter
CHM-SGT1400H/1700H Double rotray sheeter machine , Refence weight of cutting paper :150-1000gsm.
CHM-SGT1400H -Max. cutting width: 1500mm (59")
CHM-SGT1700H -Max. cutting width: 1700mm (66.9")
CHM-SGT1700H -Max. cutting width: 1900mm (74.8”)
Options Automatic Paper Splicing System& Pallet Change System& Pneumatic Slitting Knife System
Equipped with 6 servos, automatic positioning, and serial cutting functionality, it features automatic blade lowering/raising and automatic blade closing/retracting. With an extremely short setup time of less than 10 seconds, it can significantly boost productivity.Cut down on labor input and minimize wastage—maximize your savings! Reach out to us ! Share your requirements—gsm, size, reel width, and paper type—and we'll craft a tailor-made optimal solution just for you!
CHM-Machinery Ms.Ada Mob Whatsapp/Wechat :86-132 1524 2947
Email:chm017@szchm.com
Main Technology
- Heavy-weight paper compatibility – Handles cardstock, coated paper, kraft paper, cultural paper, offset paper, glossy photo paper, metallic cardstock, aluminum foil, laser holographic paper, and tobacco/liquor packaging materials.
- Precision cutting – Equipped with high-precision dual-rotary blade technology, achieving a cutting accuracy of ±0.3mm, leading the industry in slitting performance.
Synchronize -fly Sheeter features fibreless and clean cuts with high dimensional precisions.
| Type of cutting | Top blade and bottom blade rotary |
| Weight of paper | 150-1000 GSM |
| Number of rolls cutting | 4 rolls |
| Reel diameter | Max 1800mm (71") |
| Finished width | Max 1500mm (59") |
| Finished sheet length | Min 400 - Max 1700 mm |
| Total power | 98KW |
| Voltage | AC380V/220V x 50Hz |
| Parameter | Details |
|---|---|
| Model | CHM-SGT1500H II |
| Cutting Accuracy | ±0.5mm (L < 1000mm) ±0.1% (L ≥ 1000mm) |
| Max Speed of Cutting | 400 cuts/min |
| Max Cutting Speed | 300 m/min |
| Requirement of Air Pressure | 0.8 MPa |
| Output | Depends on material, weight of paper, and operating process |
Established in 2004, CHM Machinery specializes in paper sheeter machines and A4 production lines. With three factories in Guangdong, Shandong, and Jiangsu covering 140,000 square meters, we've grown to become the world's second largest sheeting machine manufacturer with independent production capacity.
Our annual production exceeds 200 units, exported to over 100 countries worldwide. We offer customized solutions based on your specific paper type, gram weight, width, and capacity requirements.
Our machines offer exceptional stability with ±0.3mm cutting accuracy. They handle a wide range of paper weights from 65g to 800g. The fully automatic configuration reduces labor while increasing production capacity.
Yes, we have numerous successful installations demonstrating our ±0.3mm accuracy, including major paper mills like ND Paper and Zhonghua Commerce.
As pioneers in China's paper sheeter machine industry with over 21 years of experience, we offer unmatched expertise. Our engineers average 15+ years of experience, and many customers have used our equipment for over a decade.
We conduct pre-production samples before mass production and final inspections before shipment. All parts are guaranteed for one year, with lifetime maintenance support.
